High-speed Three-side Sealing Bag-making Mchaine(Pouch/Zip Bag)
1.Characteristics
controlled by servo system matching with industry control grade computer.this machine can reach the orientation of high precision and high speed.when the temperature is stated,it has the advantage of ¡°speed up,not heat up¡± and can make all kinds of laminated film bags more even and more beautiful, all the parameters are displayed by the CRT at real time and it is also able to preset the bag making speed,bag making length, color cursor tracing, numbers of each batch and the transmitting time of finished product etc. besides, it is characterized in tension roll delivering, automatic alarming when the temperature exceeds the limit or color cursor loses, LPC automatic edges correction as well as double photoelectric tracking.
2.Main Technical Parameters:
|
Model: |
MK-GFQ-600B |
GFQ-400B |
|
Max. diameter of roll: mm
Max.width of roll: mm |
600
600 |
600
600 |
|
Bag maing length: mm
Bag making width: mm
Type of driving motor: |
50-500
80-600
AC triple-servo |
50-500
80-400
AC double-servo |
|
Sealing width :side sealing
Bottom sealing |
10-40
10-40 |
5-60
5-60 |
|
Sealing & cutting frequency(section/min)
Gross power:kw |
1-12
50 |
1-125
42 |
|
Air pump(mpa)
Weight: kg |
0.6
4200 |
0.6
3000 |
|
Dimensions (LXWXH)
Remarks: |
8000x2000x2100
Double zip/double pouch |
8000x1800x1700
Single zip/single pouch |
|
